How often does an airplane crash?

Why aircraft stall is so dangerous

In principle, commercial aircraft do not simply crash, even at low speeds. They are built in such a way that they have buoyancy even at speeds of just 280 kilometers per hour. The lift is created by the special wing shape. Put simply: the wing deflects the air downwards and thereby generates its own lift upwards.

This works as long as the air on the surface flows cleanly backwards. In the rear wing area there is a larger volume of air and thus a negative pressure that pulls the wing upwards.

More on this:Ethiopian passenger plane crashed

High angle of attack - vortices on the upper side of the wing

But that only works if the wing is at the right angle to the air flowing around it. If the angle becomes too steep (approx. 15 degrees or more), the streamlines at the rear end of the wing first loosen. Vortices are created. That is already a first warning signal.

It gets even worse if there is no countermeasure: the pilot has to press down the nose of the aircraft to reduce the angle of attack. In this way he avoids the eddies and can ensure buoyancy. If he does not do this and the aircraft is always steeper in the air, a dangerous stall occurs from an angle of attack of around 18-20 degrees. This means that the air above the entire wing swirls.

The wing loses its lift and thus its entire function. The plane tips forward and falls into the fall. When turning, the stall can only occur on one wing. The plane then spins and falls like a stone. Only at very high altitudes can experienced pilots regain control of a falling aircraft.

Speed ​​also plays a role

Such situations almost always end in a crash, especially when climbing. It is during this phase of flight that airliners have the most frequent accidents. Because in addition to the angle of attack, it is also about the speed of the aircraft: the slower an aircraft flies, the higher the angle of attack must be so that the aircraft has enough lift. If it does not reach the necessary "tear-off speed", the flow will stall.

Shortly after take-off, an aircraft needs considerable thrust to increase its speed and gain altitude at the same time. If the thrust decreases when climbing, this inevitably leads to a considerable loss of speed.

Which sensor should the pilot rely on?

In any case, it is important that the pilots know their speed and the angle of attack of the wings. If a sensor that supplies such data is defective, the pilots have to switch to a second - redundant - sensor. However, they must also be able to recognize which of the two sensors is wrong. If you now rely on the defective sensor, it can quickly lead to disaster.

The investigators lifted the flight recorder of Air France Flight 447 from the depths of the Atlantic Ocean

In three flight accidents in the past few decades, an incorrect speed measurement with a so-called pitot tube was the cause of the crash: Birgenair flight 301 crashed in 1996 while climbing in the Dominican Republic. There was probably dust in the speedometer there. The crash of Aeroperu flight 603 that same year had a very similar cause. Only the speedometer was not dirty there, but taped off as a precaution. The problem: Nobody had removed the adhesive strips before the start.

In both cases the speed measuring tube signaled to the pilots that the speed was far too high. In the case of the Birgenair flight, the pilot tried to counteract this by pulling the aircraft's nose up - a devastating mistake. The pilot ignored the correct data from a second speedometer and a warning signal about the impending stall, because he was probably confused and overwhelmed by the incorrect speed information.

During the Aeroperu flight, the crew was able to initiate a landing maneuver. It was only during the attempt to land that the flow stalled and the result was a crash.

The pitot tube probably iced up on Air France Flight 447 in 2009. However, here the plane was already at cruising altitude. When the autopilot switched itself off, the pilots were probably distracted by an abrupt tilting of the aircraft and tried to get the jet back under control by stalling it - too much. So they also triggered a stall that led to the crash over the Atlantic.

More on this: How safe is the Boeing 737 Max?

The Indonesian chief investigator Nurcahyo Utomo reports on findings about the Lion Air crash in 2018

Are robots really the solution?

Aircraft manufacturers try to deal with the known danger in two ways: On the one hand, pilots are specifically trained to deal with incorrect measurement data from sensors and to interpret them correctly despite confusion and possible panic.

On the other hand, the technology should improve and also intervene when stressed pilots make wrong decisions. Boeing has introduced a "Maneuvering Characteristics Augmentation System" (MCAS), which can recognize critical flight situations in the 737 Max models and intervene in the event of an impending stall, but only when the autopilot is switched off. This can be the case, for example, shortly after take-off in a climb, but also when sensors deliver unreliable measurement data - as was the case with the Air France flight.

However, the MCAS system is also associated with the crash of Lion Air Flight 610 in October 2018. Apparently it was not the speedometers that were faulty here, but the sensors that determine the angle of attack of the wings. The two sensors deviated from each other by up to 20 degrees. This accident also occurred shortly after the start in the critical climb phase.

While the investigation is still ongoing, there is some evidence that the MCAS tried repeatedly to descend prior to the crash, while the pilot tried 26 times to pull the aircraft's nose up again.

Even when Ethiopian Airlines flight 302 crashed on March 10, 2019, there was at least one indication of a connection to the MCAS system. The flight monitor service "Flightradar 24" recorded an "unstable vertical speed". That could mean that pilots and robots may have worked against each other. However, it will be clear at the earliest when the flight recorder has been found and evaluated.
